| 제품 |
MAXS-460AL |
MAXS-660AL |
MAXS-860AL |
| 절단능력 |
환재(φ) |
10 ~ 460 |
10 ~ 660 |
200 ~ 860 |
| 0.39 ~ 18.11 (inch) |
0.39 ~ 25.98 (inch) |
7.87 ~ 33.85 (inch) |
| 각재(mm) |
10×10 ~ 460×460 |
10×10 ~ 660×660 |
200×200 ~ 860×860 |
| 0.39×0.39 ~ 18.11×18.11 (inch) |
0.39×0.39 ~ 25.98×25.98 (inch) |
7.87×7.87 ~ 33.85×33.85 (inch) |
| 톱날치수(길이x폭x두께)(mm) |
6170 x 34 x 1.1t |
7600 x 41 x 1.3t |
9600 x 54 x 1.6t |
| 242.91 x 1.33 x 0.04 (inch) |
299.21 x 1.61 x 0.05 (inch) |
377.95 x 2.12 x 0.06 (inch) |
| 테이블높이(mm) |
800 |
800 |
800 |
| 31.50 (inch) |
31.50 (inch) |
31.50 (inch) |
| 기계치수(WxLxH)(mm) |
3300 x 2637 x 2430 |
3906 x 2637 x 2972 |
4600 x 2900 x 3200 |
| 129.92 x 103.82 x 95.67 (inch) |
153.78 x 103.82 x 117.01 (inch) |
181.10 x 114.17 x 125.98 (inch) |
| 기계무게(ton) |
7.2 |
9 |
15 |
| 15,873 (lbs) |
19,842 (lbs) |
33,069 (lbs) |
